PES Membrane General Grade Filter Cartridges

 Available in a variety of configurations allowing easy installation in virtually any

Filtration system.

 High Contaminant Holding Capacity

 Non-Fiber Releasing

 Provide outstanding particle retention while maintaining high flow rates.

 Enhanced porosity results in low differential pressures and extended filter life.

 Suitable for Final filtration Application

 Fast Rinse-Up to 18 Megohm-cm

Retention Ratings:

0.1, 0.2, 0.45, 0.65, 1.2um

Maximum Differential Pressure:

70psid @ 68℉ (4.8bar @ 20℃)

36psid @ 150℉ (2.5bar @ 65℃)

Recommended Change out Differential Pressure: 35psid (2. 0 bar)

Purity:

PESG Series filter cartridges are free of surfactants, anti-static agents, binders, and adhesives.

Sterilization:

Multiple autoclaving for 30 minutes at 121℃ under no end load conditions.

Materials of Construction:

Filter Media: Single layer of hydrophilic polyethersulfone membrane

Endcaps: Polypropylene

Extended Core*: Polypropylene

Gaskets/O-rings*: Silicone, Buna N, Viton A, EPDM, T = PTFE

Typical Effective Filtration Area:

>0.6 cm2 per 10”(250mm) cartridges

Dimensions (nominal):

Outside Diameter: 2.7″(68mm) (nominal)

Lengths: 5’, 250mm, 10”(254 mm), 500mm, 20”(508mm), 750mm, 30”(762 mm), 1000mm, 40”(1020mm),

50”(1270 mm), other special available.

 DI Water

 High purity water

 Washing machine

 Final filtration of Pharmaceutical and biological, Beer, Beverage, Mineral water.
